On-Board Links
NOTE: In Comfort Sync
®
systems with a conventional
outdoor unit (non-communicating), the on-board clippable
links must be set to properly congure the system.
Carefully review all conguration information provided.
Failure to properly set DIP switches, jumpers and on-
board links can result in improper operation!
WARNING
On-Board Link W914 Dehum (R to DS)
On-board link W914, is a clippable connection between
terminals R and DS on the integrated control. W914 must
be cut when the furnace is installed with either the zone
control or a thermostat which features humidity control. If
the link is left intact the PMW signal from the zone control
will be blocked and also lead to control damage. Refer to
Table 12 for operation sequence in applications including
A80US2VX, a thermostat which features humidity control
and a single-speed outdoor unit. Table 13 gives the
operation sequence in applications with a two-speed
outdoor unit.
On-Board Link W951 Heat Pump (R to O)
On-board link W951 is a clippable connection between
terminals R and O on the integrated control. W951 must
be cut when the furnace is installed in applications which
include a heat pump unit and a thermostat which features
dual fuel use. If the link is left intact, terminal “O” will remain
energized eliminating the HEAT MODE in the heat pump.
On-Board Link W915 2 Stage Compr (Y1 to Y2)
On-board link W915 is a clippable connection between
terminals Y1 and Y2 on the integrated control. W915 must
be cut if two-stage cooling will be used. If the Y1 to Y2
link is not cut the outdoor unit will operate in second-stage
cooling only.
Operating Sequence System Demand System Response
System Condition Step
Thermostat Demand Relative Humidity
Compressor
Blower
CFM
(cool)
Comments
Y1 O G W1 Status D
NO CALL FOR DEHUMIDIFICATION
Normal Operation 1 On On On Acceptable 24 VAC High 100%
Compressor and indoor blower follow
thermostat demand
BASIC MODE (only active on a Y1 thermostat demand)
Normal Operation 1 On On On Acceptable 24 VAC High 100%
Thermostat energizes Y1 and de-
energizes D on a call for de-humidication
Dehumidication Call 2 On On On Demand 0 VAC High 70%*
PRECISION MODE (operates independent of a Y1 demand)
Normal Operation 1 On On On Acceptable 24 VAC High 100%
Dehumidication mode begins when
humidity is greater than set point
Dehumidication Call 2 On On On Demand 0 VAC High 70%*
Dehumidication Call
Only
1 On On On Demand 0 VAC High 70%*
Thermostat will try to maintain room
humidity setpoint by allowing the
room space to maintain a cooler room
thermostat setpoint**
Jumpers at indoor unit with a single stage outdoor unit
With Condensing unit - Cut W914 (R to DS) on SureLight
®
control
With Heat Pump - Cut W914 (R to DS) & W951 (R to O) on SureLight
®
control
*Dehumidication blower speed is 70% of COOL speed for all units.
**In Precision mode, thermostat will maintain room temperature up to 2 °F (1.2°C) cooler than room setting.
Table 12. Operating Sequence
A80US2VX, Non-Communicating Thermostat with Humidity Control Feature and Single-Speed Outdoor Unit
