Safety Information – [cont’d]
Meaning of Pictograms
Pictograms are used to rapidly communicate
information. For the purposes of this manual and
labels affixed to the Allied equipment, pictograms are
defined as follows:
Read the manual
Refer to the manual for further
details
Procedures are explained in
the manual
Read the Service Manual For
Additional Information
Crush point
Pinch point
Moving part (in direction indicated
by arrow)
Falling object
Unsupported loads
Personal Protection Equipment
Hearing protection
Safety eyewear
Gloves
Safety shoes
Falling part
Personnel maintain a safe
distance from breaker
Fragments / debris
becoming airborne
projectiles
Protective guards required
on cab when operating this
work tool
Leaking fluid under
pressure
Hot surfaces
Gas / Oil under pressure
Shut off carrier & remove
key before servicing
Identifies lift point
Figures marked with an X-
out or circle with a diagonal
slash describe a prohibited
action.
Prohibited actions must be
avoided to prevent injury
and/or equipment damage
The check mark symbol is
used to indicate actions
and methods that are
recommended, correct and
approved
