5. Setting stroke
5.1 Easy settings of the stroke (parameter LsI
LsI LsI
LsI ≠ P
PP
P
)
Be sure that the limit switches are connected and correctly adjusted
Press and keep pressed the buttons UP[+] e MENU
for at least 5 seconds.
The gate moves in opening.
If the gate moves in closing press the button
DOWN to stop and reverse the direction of
movement and give a step by step command
(SS) to resume the procedure
Unlock the gate and move it to the middle of the stroke
When the gate reaches the opening limit switch it
stops by itself
The gate moves in closing
When the gate reaches the closing limit switch it stops
by itself
The gate moves in opening
1
2
3
4
5
When the gate reaches the opening limit switch it
stops by itself
The gate closes with the settings of slowing
down set in the menu. When the gate is closed
the learning phase is ended.
4. Remote control learning 4. Remote control learning
Press one button of the transmitter
On the display will appear
and the flashing light lights on
Make sure that the board is out of any
menus, press the button UP[+]
4.1 Learning of one transmitter
The 1st memorized button performs the STEP by STEP function (opening and closing of the gate), the 2
nd
button performs the partial opening, the 3
rd
button performs the OPEN function, 4
th
button performs the CLOSE function.
The control unit exits from the learning phase if no new button or trasnmitter command is given in 10 seconds.
On the display will appear don
dondon
don.
If the transmitter was already
memorized will appear Fnd
FndFnd
Fnd.
After 2 seconds the display will show the
memory location of the memorized transmitter,
for example
If you want to memorize another button or a new
transmitter repeat the procedure
4.2 Learning with the hidden button of an already memorized transmitter
With the hidden button of a transmitter it is possible to enter the learning phase in order to memorize new buttons or new transmitters.
With the automation still, with the aid of a clip press the hidden button of an already memorized transmitter, the flashing light lights on, now it is
possible to memorize new buttons or transmitters.
4.3 Cancellation of one transmitter
1
2
Enter the learning phase with the UP[+] button or with the hidden button of a memorized transmitter (see 4.1 or 4.2).
Press in the same time the hidden button and 1
st
button of the transmitter that you want to cancel.
The flashing light bilnks 4 times and on the display will appear
Warning: in case of intervention of a safety device, the learning is stopped and will appear on the display the written
Press Step by Step button to start again the learning from the 2
nd
point.
