LED DIAGNOSTICS
AC/PWR ON: Will be lit when AC power is ON.
M/S LINK: Will be lit when master/slave communication is active.
ALARM: Two states.
1st state: LED will blink(horn will beep also) every 30 seconds when battery is low, bad or
disconnected.
2nd state: LED will turn on for 5 minutes when operator goes on shut down mode do to the
gate hitting an obstruction(E.R.D.). Also, the horn will go off for 5 minutes.
LOW BATTERY: Three states.
1st state: LED will be on solid when battery is low.
2nd state: LED will blink slow(about every 2 seconds) when an overload occurs(over
current).
3rd state: Will blink fast(abouty every ½ second) when gate is jammed or motor sensors
Are not responding or disconnected.
OPEN-LIMIT: LED will be on while limit nut is against open limit switch.
CLOSE-LIMIT: LED will be on while limit nut is against close limit switch.
OPENING: LED will be on while operator is in the open cycle(running open).
CLOSING: LED will be on while operator is in the close cycle(running close).
RADIO: LED will turn on while radio input is activated(closed circuit to COMMON).
EXIT: LED will turn on while EXIT input is activated(closed circuit to COMMON).
PHANTOM: LED will turn on while PHANTOM input is activated(closed circuit to COMMON).
SAFETY: LED will turn on while SAFETY input is activated(circuit is open from COMMON).
PED-SW: LED will turn on while PED-SW input is activated(circuit is open from COMMON).
3BT: LED will turn on while 3BT input is activated(closed circuit to COMMON).
EDGE: LED will turn on while EDGE input is activated(closed circuit to COMMON).
TIMER LED: LED will blink when timer is counting (on the open position only).
CHRG: LED turns on when battery is charging.
24
