i. Enabled (Default)
ii. Disabled
b.
VLAN – Allows the phone to stay on the same network without any hardware reconfiguration.
i. Enabled
ii. Hub Debug Mode (Default)
iii. Disabled
c.
Remote Plug ‘n’ Play – Key used to set up a remote phone. See the System Administrator.
d.
Edit Time Server IP – Option to change the Time Server the phone is logged into.
e.
Edit Boot Server IP – The WAN IP address the server is using for the setup of a remote phone.
f.
Edit Phone Server IP – Option will appear if DHCP is disabled. Allows the manual entry of the
phone’s IP.
g.
Edit Netmask IP – Option will appear if DHCP is disabled. Allows the manual entry of the
Netmask IP.
h.
Edit Gateway IP – Option will appear if DHCP is disabled. Allows the manual entry of the
Gateway IP.
i.
Phone VLAN Settings – Option will appear if VLAN is enabled.
i. Enter VLAN ID – 2 (Default)
ii. Enter VLAN Priority – 7 (Default)
j.
PC VLAN Settings – Option will appear if VLAN is enabled.
i. Enter VLAN ID – 1 (Default)
ii. Enter VLAN Priority – 0 (Default)
4. Select the EXIT soft key.
5. Select the YES soft key to save any changes OR select NO to cancel changes made.
7.8 Current Status / Info
1. Select the CONFIG soft key.
2. Highlight Current Status/Info.
3. Press the Select button.
4. The following information is listed:
• DHCP Lease Time (if DHCP is enabled)
• SNTP Time Server IP
• Boot Server IP
• Phone IP
