Module box, variant without cooling
6
5
7
8
1
3
4
2
1 Compressor
2 Condenser
3 Vibration isolator (4x)
4 Lifting lug (4x)
5 Evaporator
6 Heat source circulation pump
7 Heatsourcellinganddraintap
8 Heatingllinganddraintap
Module box, variant with cooling
6
5
7
9 8
1
2
3
4
1 Compressor
2 Condenser
3 Vibration isolator (4x)
4 Lifting lug (4x)
5 Evaporator
6 Heat source circulation pump
7 Heatsourcellinganddraintap
8 Heatsourcellinganddraintap
9 Heatingllinganddraintap
