ALPHA TECHNICS PRECISION TEMPERATURE
4600 SERIES THERMOMETER
ALPHA TECHNICS PRECISION TEMPERATURE
4600 SERIES THERMOMETER
- SPECIFICATIONS -
MODEL 4600-2 SPECIFICATIONS:
THERMISTOR: 10k Ohms @25°C used in
Alpha Technics’ Series 2400 probe housings.
PROBE CONNECTION: 1/4” phone jack,
permanently attached, or custom
MEASUREMENT RANGE:
-40.00°C to +150.00°C
(40.00°F to +299.98.00°F)
RESOLUTION:
0.01°C (0.01°F) from -40 to 102°C
(-40 to 215°F)
0.02°C (0.05°F) from 102 to 150°C
(215 to 299.98°F)
REPEATABILITY:
0.002°C to 0.01°C at -20 to 70°C
(0.004 to 0.02°F) at (-4 to 158°F)
typical for one week at constant
ambient temperature
SYSTEM ACCURACY: (probe + thermometer)
When used in combination with a 0.1°C probe,
the thermometer/probe system will have an
overall system accuracy of ±0.13°C or better
when the temperature to be measured is
between 0°C and +70°C.
High system accuracy over a range of 0°C
to 100°C is available by multiple point
temperature calibration. Accuracy equaling
that of the meter itself, at those temperatures,
are possible.
21
- O P E R A T I N G I N S T R U C T I O N S -
5. KEY PAD OPERATION:
When the MODE key is pressed, the active
function icon flashes and the other function
icons turn on solid. Pressing MODE again
scrolls the display to the next function. When
the desired function icon is flashing, pressing
F1 or F2 assigns that function to the selected
key and enters the thermometer into that
selected function mode.
If a function has not been selected, the MODE
operation will automatically end after four
flashes of the display (about 4 secs.) or if
MODE is scrolled past C/F or CHK CAL*.
*Some versions do not have the CHK CAL function.
6
6
