37
0170009-J0 Rev B
Output
Output -
INV mode
Voltage
115V 115V, adjustable to 100/110/115/120/127
230V 230V, adjustable to 200/208/220/230/240
Voltage Regulation ≤ ± 1% until low battery warning
Frequency(Synchronized
Range)
3Hz or 1Hz (setting by software)
Frequency(Battery Mode) ±0.1% (0.05~0.06Hz) unless synchronized to line
Current
Crest Factor
PF=0.8 2.7:1
Harmonic Distortion
1KVA,2KVA, 3KVA ≤ 3% THD(Linear Load)
1.5KVA ≤ 4% THD(Linear Load)
≤ 7% THD(Non-Linear Load)
Transient Response (ms) ≤ 60ms/±5%
Waveform Pure sine wave
Efciency
To AC Mode (Full load) 85% 85% 88%
To Battery Mode (Full load) 83% 83% 85%
Battery Parameters
Model number AIDCO 1 kVA AIDCO 2 kVA AIDCO 3 kVA
Type 12V/7.2Ah 12V/7.2Ah 12V/9Ah
Number of Batteries 3 6 6
Backup Time (Full Load) PF=0.8 >5min. >5min. >4min.
Recharging Time 4 Hours to 90%
Charging Current (Max.) 1.8A 2.16A 2.7A
Charging Voltage 41.0Vdc ±0.5V 82.0VDC ±0.5V 82.0VDC ±0.5V
Hot Swappable Battery Yes
Internal battery Yes
DC leakage current
≤ 30uA (±10uA) with no AC applied and the unit in the off
position
Battery type Sealed, non-spill, maintenance-free, lead acid
Transfer Time
AC to DC Zero
Inverter to Bypass 2.5ms (Typical) Zero
DC Start Yes
Self Diagnostics By button on the panel or Software Control
Front Panel
LED
Load Level/Battery Level/ Battery Mode/ Normal Mode/
Bypass Mode/ Self-Test/ Weak/Bad Battery/Site Wiring Fault/
Fault/ Overload/Programmable Outlet1//Programmable
Outlet2
Key ON Button/ OFF Button/ (Test/Alarm Reset Button)
