0170009-J0 Rev B
38
Protection
Overload
(AC Mode )
<105% continuous
>106%~120% for 30 sec transfer to bypass
>121%~150% for 10 sec transfer to bypass
>150% for immediate transfer to bypass
Buzzer continuously alarms.
(Battery Mode)
<105% continuous
>106%~120% for 30 sec shut down
>121%~150% for 10 sec shut down
>150% for immediate shut down
Buzzer continuously alarms.
(Bypass Mode)
<105% continuous
>106%~120% for 250 sec shut down
>121%~130% for 125 sec shut down
>131%~135% for 50 sec shut down
>136%~145% for 20 sec shut down
>146%~148% for 5 sec shut down
>149%~157% for 2 sec shut down
>158%~176% for 1 sec shut down
>177%~187% for 0.32 sec shut down
>188% for 0.16 sec shut down
Buzzer continuously alarms.
Short Circuit
Bypass mode : Input Fuse/Input Breaker
Normal Mode: Output Breaker/Electronic Circuit
Battery Mode: Output Breaker/Electronic Circuit
Battery ABDM
EPO UPS shuts down immediately
Over Temperature
Normal Mode Transfer to Bypass Mode
Battery Mode UPS shuts down immediately
Audible Alarm
Battery Mode Sounding once every 1.5 sec
Low Battery Sounding once every 0.2 sec
Overload Sounding once every 3 sec
Fault Continuously Sounding (or Sounding once every 3 second)
Environmental
Operating Temperature +32°F to + 104°C (0°C to + 40°C)
Storage Temperature +5°F to + 104°F (-15°C to + 40°C)
Relative Humidity 0% to 90%, non-condensing
Noise Level <50dBA
