Alpha AS600M Series - PA: Motor Parameters

Chapter 4 Parameter Index
40
Function
code
Parameter name Setting range
Factory
setting
Modify
flag
Modbus
address
P9.16 AVR function
0: Failure to actuate
1: Run all the time
2: Not act only during
deceleration
2 × 0A10
P9.17
Overmodulation
action
0: Invalid
1: Valid
0 × 0A11
P9.18
Droop control
(load
distribution)
0.00~10.00Hz 0.00Hz ○ 0A12
P9.19
Output voltage
offset source
0: Digital setting
1: Terminal AI1
2: Terminal AI2
3: Terminal AI3 (reserve for
3004GB and below
models)
4: Pulse input
5: Communication setting
Maximum output voltage is
100%
Valid only in V / F separation
mode
0 × 0A13
P9.20
Output voltage
offset
0.0%~100.0% 0.0% ○ 0A14
P9.21
Oscillation
suppression
coefficient
0~100 0 ○ 0A15
PA: Motor Parameters
Function
code
Parameter name Setting range
Factory
setting
Modify
flag
Modbus
address
PA.00 Motor selection
0: Use motor 1
1: Use motor 2
0 × 0B00
PA.01
Number of poles
of motor 1
2~56 4 × 0B01
PA.02
Rated power of
motor 1
0.4~999.9kW
Depend on
model
× 0B02
PA.03
Rated speed of
motor 1
0~24000r/min ○ 0B03
PA.04
Rated current of
motor 1
0.1~999.9A × 0B04
PA.05
No-load current
I0 of motor 1
0.1~999.9A × 0B05
PA.06
Stator resistance
R1 of motor 1
0.001~65.000Ω ○ 0B06
