1.1 Unpacking Inspection
All drivers have passed the strict tests before delivery. After unpacking, please check if
the product is damaged by careless transport, whether the product specification and
model are complied with the order, and if it has a quality check passed mark. If there
is any problem, please contact the supplier.
1.2 Naming Rule
The naming rule of the product is as following
AS600
M
-
5R5
T3
E
Series code
Alpha Servo600 Series
Motor code
M:Special for Servo spindle
Power of motor
5R5:5.5KW
015 15KW
110: 110kw
Encoder type
E:increment pulse code
Input voltage rating
T3:3-phases 380V
Figure 1-1 Model code
1.3 Nameplate of Driver
On the lower right side of driver, there is a nameplate, which marks the model and
rated value of driver, as follows:
Figure 1-2 Nameplate of driver
AS600M-022T3E
Drive
r
model
Ada
p
tive motor
Rated input voltage,current,
Rated output voltage, current,
Barcode information
Production data, Software
i
