Alphamount APMFK2 - Step 4 Verify that the Mount is Firmly Mounted

3B-4
Install arm assembly / wall
plate using lag screws [A1].
Tighten the lag screws [A1]
only until they are pulled
firmly against the wall plate.
DO NOT over-tighten the
lag screws.
7/16″ (11mm)
Socket Wrench
(Not lncluded)
Step 4 Verify that the Mount is Firmly Mounted
70 lbs /
31.8 kg
HEAVY! You may need
assistance with this step.
A1A1
A1
A1
A1
A1
A1
A1
