Alphamount APTVS06 - Option C: TVs with a Bump; Option D: Cable Interference

Option D
For cable interference or inset holes, use spacers [TV8], [TV9] and [TV10] to
create extra space between the TV and TV brackets.
Note: The spacers must be used
with steel washers [TV7] to stop
the spacers from falling down.
Alternate Spacer Setups
Spacers may be necessary for 2 holes ONLY.
Option C (For TV with A “Bump”)
TV6
TV7
TV8/TV9/TV10
TV1-2/TV3/TV5
J(Optional)
05
TV6
TV1-1/TV2/TV4
TV7
TV8/TV9
(if needed)
05
Alternate Spacer Setups
Note: The spacers must be used
with steel washers [TV7] to stop
the spacers from falling down.
08
05
TV1-2/TV3/TV5
J(Optional)
TV8/TV9/TV10
TV7
TV6
05
Alternate
Spacer
Setups
