Alphatron ALPHA BNWAS - 4 Technical Specifications

A ALPHA BNWAS
10
4 TECHNICAL SPECIFICATIONS
Power supply
18-36Volt DC
Max. current
180mA
Relay contacts
4
Transistor outputs
2
Relay switching current
30 Volt DC – 10A
250 Volt AC – 10A
30 Volt DC – 300 Watt
250 Volt AC – 2500 Watt
Transistor current
24 Volt DC – 500mA
24 Volt DC – 12 Watt
Communication interface
RS485
Protocol
NMEA
Communication parameters
4800,8,N,1
Cutting hole HxW
139 x 67 mm
Outer size HxW
144 x 72 mm
Depth
110 mm incl connector
