Alpine CDE-120R Service Manual

PARTS LIST
No. PARTS No. PARTS NAME Q’TY SECTION
1 3032 01 55 FRAME RM 1 E 4
2 3032 01 44 TOP COVER MA 1 A 4
3 3032 01 15 DAMPER F 2 E 3
4 3032 01 16 DAMPER R 1 D 4
5 3032 01 28 AR SHEET 1 A 3
6
7
8
9
10
11 3037 05 501 CHASSIS RIVET S ASS'Y 1 B 2
12 3032 05 504 CHANGE PLATE RIVET ASS'Y (M) 1 C 4
13 3032 05 301 CLAMPER ASS'Y 1 B 3
14 3037 05 301 SPINDLE MOTOR (M) ASS'Y 1 D 1,E 1
15 3037 05 02 CLAMPER ARM S 1 B 4
16 3032 05 03 CHANGE GEAR SPRING 1 D 4
17 3032 05 05 CHANGE GEAR 2 1 D 4
18 3032 05 06 FEED GEAR 1 D 3
19 3037 05 05 FEED RACK S 1 B 1
20 3032 05 53 CHANGE LOCK LEVER M 1 D 3
21
22
23 3032 05 13 CLAMPER SUB SPRING 1 B 3
24 3037 05 07 FD SUB HOLDER S 1 B 1
25 3032 05 44 TOP PLATE D 1 B 2
26 3032 05 19 SELECT LOCK ARM 1 A 1
27 3032 05 61 TRIGGER ARM M 1 C 4
28 3032 05 21 SLIDE HOOK 1 C 4
29 3035 05 55 PU SHAFT 1 B 1
30 3032 05 59 CLAMPER ARM SPRING M 1 B 4
31 3032 05 26A SELECT LOCK ARM SPRING 1 A 1
32 3032 05 62 SUSPENSION SPRING MS 4 B 3,C 1࡮4,D 2
33 3032 05 64 SELECT ARM R (M2) 1 A 2
34 3032 05 30 LINK PLATE 1 A 2
35 3032 05 36 LINK PLATE SPRINGޓS 1 A 2
36 3037 05 08 CUSHION F 1 B 1
37 3037 05 09 CUSHION R 1 B 4
38 3032 05 63 FEED SPR PLATE M 1 C 2
39 3037 05 03 PU SHAFTޓHOLDER SA 1 B 1
40 3037 05 04 PU SHAFTޓHOLDER SB 1 B 2
41 3037 05 10 CUSHION RL 1 B 4
42 3037 05 11 CUSHION FR 1 B 2
43 3032 08 03 SELECT PLATE L 1 A 1
44 3032 08 04 SELECT PLATE R 1 A 2
45 3032 08 05 SELECT PIECE L 1 A 1
46 3032 08 06 SELECT PIECE R 1 A 2
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61 6905 16 01 PICK UP SF C250 1 B 1
62 6401 04 22 DET SW P389 00 1 C 1
63
64
65
66
67
68
69
70
