Alpine CDE-120R Service Manual

PARTS LIST
No. PARTS No. PARTS NAME Q’TY SECTION
71
72 3032 10 02 MODE SW 1 A 1
73 3037 10 06 LD WIRE(AL) 1 㧮 3,C 1
74 3037 10 01 MODE SW WIRE (S) 1 A 1
75 3037 10 07 REST SW WIRE(AL) 1 C 1
76
77 3032 10 13 WIRE CLAMPER M 4 C 2,C 3,D 4,E 3
78 3032 10 28 WIRE TUBE SPM 2 D 2
79 3032 10 29 WIRE TUBE MSW 1 A 1
80
81 3032 11 307 ROLLER SHAFT ASS'Y 1 E 2
82 3032 11 501 LOADING GEAR PLATE RIVET ASS'Y 1 D 2
83 3032 11 302 LOADING PLATE ASS'Y 1 C 4
84 3032 11 506 LOCK ARM RIVET ASS'Y (RV) 1 E 1
85 3037 11 301 LOADING/FEED MOTOR ASS'Y (M) 1 B 3
86 3032 11 01 LOADING GEAR 1 1 D 4
87 3032 11 02 LOADING GEAR 2 1 D 3
88 3032 11 03 LOADING GEAR 3 1 D 3
89 3032 11 04 LOADING GEAR 4 1 D 2
90 3032 11 05 LOADING GEAR 5 1 D 2
91 3032 11 06 LOADING GEAR 6 1 D 2
92 3032 11 07 LOADING GEAR 7 1 D 3
93 3032 11 49 ROLLER GUIDE (N) 2 D 1,E 3
94 3032 11 14 ROLLER GUIDE SPRING 2 D 1,E 1
95 3032 11 53 DISC STOPPER ARM (N) 1 C 1
96 3032 11 17 DISC STOP ARM SPRING 1 D 2
97 3032 11 18 LD GEAR BRACKET 1 D 2
98 3032 11 25 L SLIDE PLATE 1 D 4
99 3032 11 31 LOADING PLATE SPRING 1 C 4
100 3037 11 04 LDG ROLLER (C) 2 D 1
101 3032 11 43 COLLAR SCREW 1 E 1
102 3032 11 42 LOCK ARM SP 1 E 1
103
104
105
106
107
108
109
110 9P04 20 061 TAPPING SCREW 2×6 1 C 1
111 9P04 20 031 TAPPING SCREW 2×3 5
A
3,B 3࡮4,D 2,E 4
112 9P04 20 041 TAPPING SCREW 2×4 2 B 1,B 2
113 9B03 20 041 TAPPING BIND SCREW 2×4 1 D 2
114 9C01 17 183 CAMERA SCREW 1.7×1.8 2 B 2
115 9C01 20 203 CAMERA SCREW 2×2 1 C 3
116 9C45 17 503 CAMERA TAPPING SCREW P3 M1.7×5 1 C 1
117
118
119
120
121 9W01 30 170 PW 3.5×8×0.3 1 D 4
122 9W26 20 010 SUS W2.05×4.2×0.2 1 D 1
123 9W07 10 070 LUMILAR WASHER 3.1×6×0.1 1 D 1
124 9E01 00 152 E RING S 1.5 1 D 4
125 9W01 13 020 PW 2.1×4×0.13 1 D 3
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
