Alpine CDE-120R Service Manual

Model : CDE-120R/RM/RR
These parts have been selected by AOEU Service as must be available parts from EPC
Only parts as shown on this page can be ordered from EPC!!
!
POSITION Nr: PART Nr: DESCRIPTION
Not Known 6899-12-61 Power Supply Cord
Not Known 7210-01-15 Mount Frame (Inner Case)
Not Known 7236-07-301 Carrying Case Assy
Not Known 7210-07-01 Removal Key
3 7236-01-01 Face Plate
30 7233-03-302 Front Escutcheon Assy
50 7238-04-301 Panel Assy 120R (Nose Unit)
50 7238-04-302 Panel Assy 120RM (Nose Unit)
50 7238-04-303 Panel Assy 120RR (Nose Unit)
53 7236-04-05 Knob Rotory
54 7201-04-71 Knob Spring
80 TN-2002-1005 CD Mechanism
Not Known
6905-16-01 Laser (Pick-up)
62
7238-05-301
Front PWB Assy
62 7238-05-302 Front PWB Assy
62 7238-05-303 Front PWB Assy
SW901 EC12D1524403 Rotary Encoder
D921 - D931 SML-D12P8WT86 LEDs(Green)
D932 KLB-16G LED(Green)
D921 - D932 SML-D12D8WT86 LEDs(Amber)
D921 - D932 SML-D12V8WT86S LEDs(Red)
CN901 DF20-P Connector
CN951 CU01SAV1S0A-L Connector USB
IC901 LC75857W-UMSE Display Controller IC
LD901 JIC-TR012424DN Display
IC801 MN66279462TC CD DSP
PA051 MX-E210-80-2290 Tuner MX-E210
CN971 DF20-S Connector
IC201 TDA7418TR TDA7418TA
IC271 LV47002P-E LV47002
IC751 AN34001A-LC AN34001A
IC601 MNBE16YTAUB Controller IC601
IC501 SAA6588T-V2H518 SAA6588T
If you require any parts other than the ones listed on this page we will of course try our best to
obtain them for you, requests should Only directed to AOEU Service on this e-mail address:
service-europe@alpine.de
but please note that if we manage to obtain the requested parts delivery could take sometime,
the above list will be monitored and parts will be added as and when required.
