Alpine CDE-121E User Manual

11-EN
Displaying the Text
Text information, such as the disc name and the track name, will be
displayed if playing a CD text compatible disc. It is also possible to
display the folder name, the file name and the tag, etc., while playing
MP3/WMA/AAC files.
Press VIEW .
The display will change every time the button is pressed.
TRACK NO./ELAPSED TIME TEXT (DISC NAME)
TEXT (TRACK NAME) TRACK NO./ELAPSED TIME*
1
*
1
FILE NO./ELAPSED TIME FOLDER NO./FILE NO.
FOLDER NAME FILE NAME ARTIST NAME
*
2
ALBUM NAME*
2
SONG NAME*
2
FILE NO./ELAPSED TIME
*
1
Displayed during playback of a disc with CD text.
*
2
ID3 tag/WMA tag
If an MP3/WMA/AAC file contains ID3 tag/WMA tag information,
the ID3 tag/WMA tag information is displayed (e.g., song name,
artist name, and album name). All other tag data is ignored.
Other Functions
VIEW
SOURCE/
Setting the Treble Control
You can change the Treble Frequency emphasis to create your own tonal
preference.
1 Press SOUND repeatedly to select the TREBLE
mode.
BASS TREBLE BASS
2 -1 Press BAND to select the desired treble centre
-1 frequency.
10.0 kHz 12.5 kHz 15.0 kHz 7.5 kHz 10.0 kHz
Emphasises the displayed treble frequency ranges.
2 -2*
2
Turn the Rotary encoder to select the desired
treble level (–7~+7).
You can emphasise the treble level.
3 Press and hold /ESC for at least 2 seconds to
return to normal mode.
• If no operation is performed for 15 seconds, the unit will return to
normal mode automatically.
The treble level settings will be individually memorized for each
source (FM, AM, CD, etc.) until the setting is changed. The Treble
frequency settings adjusted for one source are effective for all other
sources (FM, AM, CD, etc.).
The function is inoperable when DEFEAT is set to ON.
• Press and hold VIEW for at least 2 seconds, the current text will
be scrolled one time (except Radio mode).
•
•
*
2
The adjustment can also be made by pressing Rotary encoder.
Refer to “Adjusting Subwoofer Level/Bass Level/Treble Level/
Balance (Between Left and Right)/Fader (Between Front and Rear)/
Defeat” (page 10).
Loudness Setting
Setting the Treble Centre Frequency
Setting the Treble Level
About the indication display
When displaying Text, the following indicators are lit
according to the mode.
*
1
Tag information
If there is no tag information, “ARTIST”/“ALBUM”/“SONG” is
displayed.
*
2
The root folder is displayed as “ROOT”.
*
3
If there is no Text (Disc Name or Track Name), “DISC TEXT”/
“TRACK TEXT” is displayed.
Indicator/
Mode CD Mode
MP3/WMA/AAC/
USB AUDIO
Mode
iPod/iPhone
Mode
––
Folder Name*
2
being displayed
––
––
Artist Name*
1
being displayed
Artist Name*
1
being displayed
Text (Disc
Name*
3
) being
displayed
Album Name*
1
being displayed
Album Name*
1
being displayed
Text (Track
Name*
3
) being
displayed
Song Name*
1
/
File Name being
displayed
Song Name*
1
being displayed
The display in MP3/WMA/AAC mode:
The display in CD mode:
Loudness introduces a special low-frequency emphasis at low listening
levels. This compensates for the ear’s decreased sensitivity to bass
sound.
Compared with LOUD 1, LOUD 2 farther emphasises the enhancement
of bass frequency to realise super bass.
Press and hold Rotary encoder (LOUD) for at least 2
seconds to switch the desired mode.
• The function is inoperable when DEFEAT is set to ON.
LOUD OFF LOUD 1 LOUD 2 LOUD OFF

Alpine CDE-121E Specifications

General

Brand	Alpine
Model	CDE-121E
Category	Car Receiver
Language	English
