26-EN
Specifications
FM TUNER SECTION
AM TUNER SECTION
CD PLAYER SECTION
PICKUP
USB SECTION
GENERAL
CHASSIS SIZE
NOSEPIECE SIZE
Note
• Due to continuous product improvement, specifications and design are
subject to change without notice.
Tuning Range 87.5~108.0 MHz
Mono Usable Sensitivity 9.0 dBf (0.8 µV/75 ohms)
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
Tuning Range 531~1,602 kHz
Sensitivity (IEC Standard) 22.5 V/27 dB
Frequency Response 5~20,000 Hz (±1 dB)
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
Wave length 795 nm
Laser power CLASS I
USB requirements USB 1.1/2.0
Max. Power Consumption 1,000 mA
USB Class Mass Storage
File System FAT 12/16/32
MP3 Decoding MPEG AUDIO Layer-3
WMA Decoding Windows Media
™
Audio
Power Requirement 14.4 V DC
(11~16 V allowable)
Maximum Power Output 50 W × 4
Maximum Pre-Output Voltage 2 V/10 k ohms
Bass ±14 dB at 100 Hz
Treble ±14 dB at 10 kHz
Loudness 10 dB at 100 Hz
Weight 1.4 kg (3 lbs. 1 oz)
Width 178 mm (7")
Height 50 mm (2")
Depth 161.5 mm (6–3/8")
Width 170 mm (6–3/4")
Height 46 mm (1–13/16")
Depth 25 mm (1")
00ALPINE.book Page 26 Tuesday, October 16, 2012 7:01 PM
