Alpine CDE-154BT Owner's Manual

23-EN
* e illustration is for CDE-173BT.
Setup Before Using
BLUETOOTH is a wireless technology allowing communication
When an iPod/iPhone is connected, the unit will auto pair with it.
between a mobile device or personal computer over short distances.
is enables a hands-free call or data transmission between
BLUETOOTH compatible devices. BLUETOOTH transmission is
available in the unlicensed 2.4 GHz spectrum if the distance between
devices is within 10 meters. For details, refer to the BLUETOOTH
Home page (http://www.bluetooth.com).
Notes
• Depending on the BLUETOOTH version, a BLUETOOTH compatible
device may not be able to communicate with this unit.
• Proper function of this unit with all BLUETOOTH compatible devices
is not guaranteed. For handling of the BT compatible device, consult
your ALPINE dealer or ALPINE website.
• Depending on the surroundings, BLUETOOTH wireless connection
may be unstable.
• When you place a call, or perform setup operations, be sure to stop your
car in a safe place.
• Depending on the connected BLUETOOTH compatible device(s), the
function may dier. Also refer to the Owner’s Manual of the connected
device(s).
• When you search this unit using the BLUETOOTH compatible phone,
the unit name is displayed (Such as CDE-154BTSeries,
CDE-185BTSeries,.etc)
Before using the BLUETOOTH function, the following settings need to
be made.
Set “BT IN” to ON when you want to use Hands-Free phone
or BT Audio function. Refer to “Setting the BLUETOOTH
Connection (BT IN)” on page 24.
Note
• Before using BLUETOOTH function, it must be paired with this unit.
Refer to “How to connect to a BLUETOOTH compatible device
(Pairing)” on page 23.
For details on the control from a BLUETOOTH compatible device, refer
to the Owner’s Manual of the BLUETOOTH compatible device.
Pairing a BLUETOOTH compatible device with
SSP (Secure Simple Pairing)
Auto pairing with an iPod/iPhone
1 Using your BLUETOOTH compatible device, select the
2 Turn the Rotary encoder to change the head unit display
from “PAIR NO” to “PAIR YES”, and then press
If “PAIR NO” is selected, the connection will be cancelled.
3 If the pairing was successful, “CONNECTED” is displayed
for a few seconds. The head unit then returns to its
previous state.
Pairing a BLUETOOTH compatible device without
SSP (Secure Simple Pairing)
1
model name for pairing.
Using your BLUETOOTH compatible device, select the
model name for pairing.
2 Input the PIN code (“0000”) in a BLUETOOTH compatible
device.
Note
• e PIN code is xed as “0000”.
3 If the pairing was successful, “CONNECTED” is displayed
for a few seconds. The head unit then returns to its
previous state.
1 Make sure USB PAIR is set to ON.(page 24)
2 Connect an iPod/iPhone to this unit.
3
4
If the pairing was successful, “CONNECTED” is displayed
for a few seconds. The head unit then returns to its
previous state.
Notes
BLUETOOTH SETUP
e following steps 1 to 5 are common to the various BLUETOOTH
functions. For details, refer to each individual function.
Note
• Set “BT IN” to ON, and then perform BLUETOOTH SETUP operation.
Refer to “Setting the BLUETOOTH Connection (BT IN)” on page 24.
1 Press and hold AUDIOSETUP for at least 2 seconds to
activate the SETUP mode.
2 Turn the Rotary encoder to select “BLUETOOTH”, and then
press ENTER.
The BLUETOOTH setup mode is activated.
BLUETOOTH Operation
About BLUETOOTH
Before Using BLUETOOTH Function


BAND/ABC SEARCH
AUDIO/SETUP

1/
2/

Preset buttons
(1 through 6)
Rotary encoder/
/ENTER

SOURCE
/ II
How to connect to a BLUETOOTH
compatible device (Pairing)
Turn the Rotary encoder select "CONNECT BT YES",
and then press
If "CONNECT BT NO" is selected, the connection will be cancelled.
ENTER.
ENTER.
• If the connection is unsuccessful, “FAILED” is displayed.
• Aer a successful pairing, the two devices should connect automatically
whenever the vehicle’s ignition is turned ON. If the auto reconnect fails,
try to connection manually.
• Set “VISIBLE M” to ON to enable this unit to be recognised by a
BLUETOOTH compatible device, refer to “Setting the Visible Mode” on
page 24.
• You can also manually pair the BLUETOOTH devices from this unit.
For details, refer to “Pairing a BLUETOOTH Device from the unit” on
page 24.
