11. INSTRUCTIONS FOR BREEZ PLUS WIRED CONNECTIONS (24V OR 12V)
Step 4: Breez Plus has two connections marked as 24V at its back. Connect C & R
wires at these two connections.
Step 5: Press fit the Breez plus on its back plate.
Your Installation is complete. Please switch
on the power from the mains.
Note:
In case of any doubt, please contact a local professional for making the wired
connections. You can also use the Breez Plus with a 5V adapter
(included in the box).
R
C
