Alpine Cielo Breez Plus - Cielo Breez Plus Wired Connections

Step 1: Switch off power by using the master switch or mains circuit breaker.
This is very important for your safety.
Step 2: Find a point where 24V or 12V is available (e.g. the point where thermostat
wiring is available). Ensure that chosen point is also in the line of
sight of your AC.
Please DO NOT use any other voltage level to power up Breez Plus.
Step 3: Choose C & R wires. Pull these wires and pass them through the hole of back
plate of Breez Plus. Screw in the back plate of Breez Plus into the wall.
16
11. INSTRUCTIONS FOR BREEZ PLUS WIRED CONNECTIONS (24V OR 12V)
BREAKER BOX SWITCH
OR
