Alpine DVA-7996 - Specifications; FM TUNER SECTION; AM TUNER SECTION; CD;DVD SECTION

54-EN
Information
Specifications
FM TUNER SECTION
Tuning Range 87.7 – 107.9 MHz
Mono Usable Sensitivity 9.3 dBf (0.8 µV/75 ohms)
50 dB Quieting Sensitivity 13.5 dBf (1.3 µV/75 ohms)
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 80 dB
Stereo Separation 45 dB
Capture Ratio 2.0 dB
AM TUNER SECTION
Tuning Range 530 – 1,710 kHz
Sensitivity (IEC Standard) 22.5 µV/27 dB
CD/DVD SECTION
Frequency Response 5 – 20,000 Hz
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Channel Separation 90 dB (at 1 kHz)
Signal system NTSC
Horizontal resolution 500 lines or greater
Video output level 1Vp-p (75 ohms)
Video S/N ratio DVD: 70 dB
Audio S/N ratio More than 115 dB
PICKUP
Wave length 655 nm
Laser power CLASS II
REMOTE CONTROL
Battery Type AAA batteries (2 pcs.)
Width 56 mm (2-1/4")
Height 142.5 mm (5-5/8")
Depth 37 mm (1-7/16")
Weight 72 g (2.54 oz)
GENERAL
Power Requirement 14.4 V DC
(11–16 V allowable)
Maximum Pre-Output Voltage 5 V/10 k ohms
Bass ±14 dB at 60 Hz
Treble ±14 dB at 10 kHz
Weight 2.0 kg (4 lbs. 7 oz)
Audio output level
Preout (Front, Rear): 5V/10k ohms (max.)
Preout (Subwoofer): 4V/10k ohms (max.)
Auxout: 1.2V/10k ohms
Ai-NET: 850 mV
CHASSIS SIZE
Width 178 mm (7")
Height 50 mm (2")
Depth 155 mm (6-1/8")
NOSEPIECE SIZE
Width 170 mm (6-11/16")
Height 46 mm (1-13/16")
Depth 18 mm (11/16")
Due to continuous product improvement, specifications and design
are subject to change without notice.
CAUTION-Laser radiation when open, DO NOT STARE INTO BEAM
(Bottom side of player)
CAUTION
