30-EN
Setting the Speakers
1
Check that Defeat mode is of f (page 19).
2
Press and hold CENTER f. for at least 2 seconds.
The audio processor control mode is activated.
3
Select the SP SELECT mode by pr essing
CENTER f. repeatedly .
4
Select each speaker by tur ning and then pr essing
the Rotary encoder.
5
Select any kind of speaker or set speaker to ON/
OFF by tur ning and then pr essing the Rotary
encoder.
FRONT1: OFF/TW (Tweeter)/FULL (Full Rang e)
FRONT2: OFF/ON
REAR: OFF/ON
CENTER: OFF/ON
SUBWOOFER: OFF/MONO/STEREO
6
When the setting is complete, pr ess and hold
CENTER f. for at least 2 seconds.
The unit returns to the normal mode.
Press CENTER f. to select another item to be set.
• Set the speaker which is not connected to OFF.
• Settings above can be carried out even when the speaker is set to
OFF in “Speaker Setup” (page 34).
•To use the subwoofer in MONO with PXA-H700 or PXA-H701
connected, connect the subwoofer to the subwoofer output terminal
of PXA-H700 or PXA-H701.
Set MX Mode of the External Audio
Processor
Before performing the operations below, set MX (Media Xpander)
mode of the PXA-H700 to “AUTO” when the PXA-H700 is
connected.
1
Check that Defeat mode is of f (page 19).
2
Press and hold CENTER f. for at least 2 seconds.
The audio processor control mode is activated.
3
Select the MX mode by pr essing CENTER f.
repeatedly .
4
Select ON/OFF of MX by pr essing g or f.
OFF: Tur ns off the MX effect of every music source.
ON: Turns on the specified MX mode.
5
After setting to ON, select the desir ed MX level by
tur ning and then pr essing the Rotary encoder.
• Music source (such as radio broadcasts and CDs, excluding MW,
LW radio) level can be set.
MX CD (OFF, CD MX 1 to 3)
CD mode processes a large quantity of data. This data is
used to reproduce the sound cleanly by making use of the
data quantity.
MX COMPRESS MEDIA (OFF, CMPM 1 to 3)
This corrects information that was omitted at the time of
compression. This reproduces a well-balanced sound close to
the original.
MX FM (OFF, FM MX 1 to 3)
The medium to high frequencies become more clear, and
produces well balanced sound in all the bands.
MX DVD (OFF, MOVIE MX 1 to 2)
The dialog portion of the video is reproduced more clearly.
(DVD MUSIC)
This disk contains a large quantity of data such as music clip.
MX uses this data to reproduce the sound accurately.
MX AUX 1 to 3 (OFF, CMPX MX, MOVIE MX, MUSIC MX)
Choose the MX mode (MP3, MUSIC, or MOVIE) that
corresponds to the media connected.
6
When the setting is complete, pr ess and hold
CENTER f. for at least 2 seconds.
The unit returns to the normal mode.
Press CENTER f. to select another item to be set.
• The contents of MX set here is reflected to PXA-H700 or PXA-
H701.
• When OFF is selected, MX effect of each MX mode will be OFF.
• Each music source, such as radio, CD, and MP3 can have its own
MX setting.
• There is no MX mode for MW, LW radio.
• MX COMPRESS MEDIA is applied for MP3/WMA, MMD.
X-OVER Adjustment
1
Check that Defeat mode is of f (page 19).
2
Press and hold CENTER f. for at least 2 seconds.
The audio processor control mode is activated.
3
Select the X-OVER mode by pr essing CENTER f.
repeatedly .
4
Select L+R or L/R by pr essing and holding BAND
for at least 2 seconds.
L+R: Sets the same adjustment values for the left and
right channels.
L/R: Different adjustment values can be set for the left
and right channels.
5
Select the desir ed channel by pr essing g or
f.
When L+R is selected :
FRONT 1 → FRONT 2 → REAR → CENTER →
SUBWOOFER → FRONT 1
When L/R is selected :
FRONT 1L → FRONT 1R → FRONT 2L → FRONT 2R →
REAR L → REAR R → CENTER → SUBWOOFER →
FRONT 1L
• The speakers display differs, depending on the connected speakers.
6
Adjust the cut-of f fr equency of H.P .F. (HP FREQ) by
tur ning and then pr essing the Rotary encoder.
The adjustable frequency range differs depending on the
channels (speakers).
To Next Page
