Jeep Wrangler
i207-WRA 20201016v1
8/19
Factory Unit Disassembly Process (2007-2010 Only)
DISCONNECT THE BATTERY BEFORE
CONTINUING. FAILURE TO DO SO WILL
DISABLE MANY FEATURES.
1 Remove top by releasing 2 rear clips on the back of
the top panel and then pull panel forward.
3 Release 2 clips on the top of the bottom panel. This
will expose two 7mm screws. Remove using a 7mm
socket with ratchet & extension.
5 Extract (4) 7 mm screws and remove the factory
radio.
2 Release 2 clips on the top of the bottom panel. This
will expose two 7mm screws. Remove those.
4 Use panel removal tool to remove dash panel by
releasing 6 clips (3 per side)
To Next Page
