67-EN
Audio/Visual
Connected USB Device is not supported.
• An iPhone that is not supported by the unit is connected.
– Connect an iPhone that is supported by the unit.
• A USB device that is not supported by the unit is
connected.
– Attempt to connect another USB flash drive.
• Communication error.
– Turn the ignition key off, and then set to ON again.
– Check the display by reconnecting between the iPhone
and the unit, using the iPhone cable.
– Check the display by reconnecting between the USB
flash drive and the unit.
• Caused by the iPod/iPhone Software Version not being
compatible with this unit.
– Update the iPhone Software Version to be compatible
with this unit.
• The iPhone is not verified.
– Change to another iPhone.
DAB Antenna error
• The DAB antenna cable is either damaged or not
connected correctly to the product.
– Check that the antenna cable is not kinked or otherwise
damaged. Replace the antenna if necessary.
• Abnormal current is run to the DAB Antenna.
– Connect the antenna properly to a car with a 12 volt
negative ground.
HDMI
HDMI communication error.
Please check your device and operate it again.
• The HDMI devices are not connected properly.
– Remove the HDMI devices from the unit, and then
reconnect them. Enable the output setting on the HDMI
devices.
HDMI monitor communication error.
Please check the connection or ACC off / on.
• Connection error
– Turn OFF/ON the engine (ACC), or check the HDMI
connection cable of the HDMI compatible monitor.
Specifications
MONITOR SECTION
Screen Size 7” (iLX-507A)
9” (iLX-F509A)
11” (iLX-F511A)
Operation System TFT active matrix
Number of Picture Elements
2,764,800 pcs. (1280 × 720 × RGB)
Effective Number of Picture Elements
99% or more
Color system NTSC / PAL
Illumination System LED
FM TUNER SECTION
Tuning Range 87.5 – 108.0 MHz
Mono Usable Sensitivity
8.1 dBf (0.7 μV/75 ohms)
50 dB Quieting Sensitivity
12 dBf (1.1 μV/75 ohms)
Alternate Channel Selectivity
80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
AM TUNER SECTION
Tuning Range 531 – 1,701 kHz
Usable Sensitivity 25.1 μV/28 dBf
DAB SECTION
Tuning Range 174.928 – 239.2 MHz
Usable Sensitivity -100 dBm
Signal-to-Noise Ratio 90 dB
USB1 SECTION
USB requirements USB 2.0
Max. Power Consumption
2,400 mA
USB Class USB (Mass Storage Class)
File System FAT16 / 32, exFAT
Number of Channels 2-Channels (Stereo)
Frequency Response*
1
5 – 40,000 Hz (±1 dB)
Total Harmonic Distortion
0.005% (at 1 kHz)
