Jeep Wrangler
i509-WRA-JK 20220404v1
3/22
Tools Required
Panel Removing Tool 7mm Sockets #2 Phillips Screwdriver
10mm Sockets Extension Ratchet
Wire Cutters Air Saw T20 Torx
Digital Multimeter
Accessory List
Installation Kit Parts
i509-WRA-JK Radio Dash Bezel Display Power/Key Harness Side Mounting Brackets
MENU
Microphone Display Mounting Brackets Source Unit HDMI Bracket
