28-EN
01GB05IVA310R.fm
ALPINE IVA-D310R 68-02278Z24-A (EN)
4
Select “ON” by touching [] or [] of V.EFFECT
within 5 seconds.
Set to OFF to cancel.
• To make the setting, set to “Setting the VISUAL Touch Button” (page
36).
• V.EFFECT is not displayed when the audio main source is selected.
• When the visual effect is set to ON, the rear monitor source cannot be
changed from the unit.
• This setting may not be performed while driving.
Monitor Setting Operation
1
Touch [SETUP] on the main source screen.
The SETUP selection screen is displayed.
2
Touch [MONITOR].
The MONITOR screen appears.
3
Touch [] or [] of the desired item to change its
setting.
Setting items:
SLIDE / MONITOR O/C (OPEN/CLOSE)
4
Touch [RETURN] to return to the previous screen.
Touch [CONTROL] to return to the main source screen that
was displayed before the setup operation was started.
The monitor can be set in 2 positions.
Setting item: SLIDE
Setting content: BACK / FRONT
• If the monitor is forcibly pushed or pulled, you may not be able to set
the monitor angle or position. In this case, press OPEN/CLOSE to
close the monitor once, and then open the monitor again.
Setting item: MONITOR O/C (OPEN / CLOSE)
Setting content: MANUAL / FULL / CLOSE
ON: Turns on the function for enhancing visual effects when
connected to two or more external monitors.
Monitor Setting
Following Steps 1 to 4 describe the common procedures for
operating the MONITOR setting function. For details of the
setting function items, refer to descriptions of respective items.
Selecting the Monitor Position
BACK: Slides the display backwards.
FRONT: Slides the display forwards.
Setting Automatic Opening/Closing of the
Monitor
MANUAL: The monitor is manually opened or closed by
pressing OPEN/CLOSE.
FULL: The monitor automatically opens or closes when the
ignition key is turned to the “ACC” or “ON/OFF”
position.
CLOSE: The monitor automatically closes when the ignition
key is turned OFF.
01GB00IVAD310R.book Page 28 Thursday, January 13, 2005 10:40 AM
