Preperation: Rear Door
Then place the push clips back ontop the door card.
The next step requires a soft test mounting of the Front Door pod. Lay the door card
down on the pod and line up your pre drill holes. We recommend using only a portion
of the provided screws at this step as the door pod will need to be removed.
53
54
Preperation: Rear Door
Take a marker and using the exocasings speaker cut out draw an oval on the sheet
metal to indicator areas that require cutting for clearance.
Place the test mounted assembly to your door by lining up the push clips with the
doors mounting holes.
55
56
