Installation: Front Exocasing
With the +/- Speaker wire and +/- USB wire routed into the rear doors of the vehicle.
Terminate them into crimp connectors or solder them to the loose wires on the door/
exocasing assembly.
Reassemble the window control panel and remount the door handle. The Front
Exocasing assembly is now installed.
89
90
Installation: Rear Exocasing
With the door card/assembly mounted, secure it with the M6 bolts supplied with the
10mm socket and wrench.
Once the wiring is complete. Mount the assembly to the door. Ensure all plastic push
clips are mounted back onto the door card.
