Parts Number From To Description

J12 (MainBoard) J2 (FrontKeyBoard) 20Pin/Pitch 1.25mm/Length 50mm/Wire28#

J14 (MainBoard) J1 (FrontPassengerBoard) 7Pin/Pitch 1.25mm/Length 210mm/Wire 28#

J11 (MainBoard) J2 (AUX3 Board) 8Pin/Pitch 1.25mm/Length 55mm/Wire 28#

J2 (TFT Board) Inverter Board 7Pin/Pitch 1.25mm/Length 70mm/Wire 28#

J13 (MainBoard) J1 (EjectKeyBoard) 7Pin/Pitch 1.25mm/Length 70mm/Wire 28#

J4 (MainBoard) J1 (FrontKeyBoard) 6Pin/Pitch 1.25mm/Length 100mm/Wire 28#

J18 (MainBoard) Speaker 2Pin/Pitch 2.54mm/Length 215mm/Wire 26#

J9 (MainBoard) 9Pin/Pitch 2.0mm/Length 360mm+70mm

J10 (MainBoard) 11Pin/Pitch 2.0mm/Length 270mm +70mm

J6 (MainBoard) DVD 45Pin/Pitch 0.5mm/Length 160mm

J7 (MainBoard) DVD 24Pin/Pitch 0.5mm/Length 170mm

CN1,CN2 (TFT Board) Panel 30Pin/Pitch 0.5mm/Length 200mm
Connecting Table
