Alpine PKG-2000P - Page 85

MN35207UB : IC601 (DV37M150)
No. Symbol I/O Terminal Description
1 MDQ9 I/O SDRAM data 9 terminal.
2 MDQ5 I/O SDRAM data 5 terminal.
3 VSS - GND terminal.
4 MDQ10 I/O SDRAM data 10 terminal.
5 MDQ4 I/O SDRAM data 4 terminal.
6 VDD33 - I/O power supply terminal.
7 MDQ11 I/O SDRAM data 11 terminal.
8 MDQ3 I/O SDRAM data 3 terminal.
9 VSS - GND terminal.
10 MDQ12 I/O SDRAM data 12 terminal.
11 MDQ2 I/O SDRAM data 2 terminal.
12 VDD33 - I/O power supply terminal.
13 MDQ13 I/O SDRAM data 13 terminal.
14 MDQ1 I/O SDRAM data 1 terminal.
15 MDQ14 I/O SDRAM data 14 terminal.
16 VSS - GND terminal.
17 MDQ0 I/O SDRAM data 0 terminal.
18 MDQ15 I/O SDRAM data 15 terminal.
19 VDD33 - I/O power supply terminal.
20 VSS - GND terminal.
21 EXADR20 I/O External memory address 20 terminal.
22 NEXWE O External memory write enable output terminal.
23 EXADT0 I/O External memory address data 0 terminal.
24 EXADT4 I/O External memory address data 4 terminal.
25 EXADT8 I/O External memory address data 8 terminal.
26 VDD12 - Logic power supply terminal.
27 EXADT12 I/O External memory address data 12 terminal.
28 VDD33 - I/O power supply terminal.
29 VSS - GND terminal.
30 EXADR16 I/O External memory address 16 terminal.
31 EXADR18 I/O External memory address 18 terminal.
32 EXADT14 I/O External memory address data 14 terminal.
33 EXADT10 I/O External memory address data 10 terminal.
34 VDD33 - I/O power supply terminal.
35 VSS - GND terminal.
36 EXADT6 I/O External memory address data 6 terminal.
37 EXADT2 I/O External memory address data 2 terminal.
38 NEXCE O External memory chip select output terminal.
39 EXADT1 I/O External memory address data 1 terminal.
40 EXADT5 I/O External memory address data 5 terminal.
41 EXADT9 I/O External memory address data 9 terminal.
42 EXADT13 I/O External memory address data 13 terminal.
43 EXADR17 I/O External memory address 17 terminal.
44 VDD12 - Logic power supply terminal.
45 EXADR19 I/O External memory address 19 terminal.
46 EXADT15 I/O External memory address data 15 terminal.
47 EXADT11 I/O External memory address data 11 terminal.
