Front Lower Dash Speaker Removal
1
Using a panel removing tools, remove the dash side
covers by each door.
2
Remove the driver side knee cover by releasing the
(2) top clips.
Driver Side Passenger Side
3
Extract (2) 10mm screws from the metal steering
wheel column cover and remove it.
4
Extract (2) 7mm screws from the lower dash.
5
Remove glove box by pushing both left and right
sides inwards.
6
Extract (2) 7mm screws located on the lower dash
section.
Jeep Wrangler
UNLIMITED JK • 7/19
