Front Speakers Removal
5
Extract (2) 7mm screws from the side of each
respective dash enclosure.
Passenger SideDriver Side
7
Disconnect the speaker enclosure (connector
located on the back)
6
Remove (1) 10mm screws from under the each
enclosure.
8
Pull the dash towards the back of the vehicle and
remove the enclosure by turning towards the back.
9
10
Extract (2) 7mm screws from the lower dash.
Remove glove box by pushing both left and right
sides inwards.
0 7-’11 Models have (4) screws)
‘07-11 Models have (2) additional screws
Front Lower Dash Speaker Removal (continued)
Center Console Shifter Panel Removal
1
2
Remove the transfer case shifter knob
by pulling up. (some force may be
needed)
Remove the shifter panel by carefully
pulling upward and releasing the clips
with a panel removal tool.
Jeep Wrangler
UNLIMITED JK • 8/19
