16-EN
2 Speaker + Subwoofer System (Bridged Connections)
(Top inner panel)
[LO]
Head Unit, etc.
Remote Turn-On Lead
Input Level Switch
2 Speaker System (Bridged Connections)
(Top inner panel)
[LO]
Head Unit, etc.
Remote Turn-On Lead
Input Level Switch
Front 2-Way System
When using the Front 2-Way System, set each switch as follows.
Crossover Mode Selector Switch
(CHANNEL-1/2)
Input Channel Selector Switch
(CHANNEL-3/4)
Crossover Mode Selector Switch
(CHANNEL-3/4)
HP-H
3/4
BP
[LO]
Head Unit, etc.
Remote Turn-On Lead
Input Level Switch
(Top inner panel)
