Chevrolet/GMC
FULL SIZE TRUCK z 8/17
Factory Radio Removal Procedure
1 Disconnect the ground wire from the negative
terminal of the battery.
2 Unsnap and remove center dash trim piece from
around the radio and climate controls.
MENU
TEMP
BACK
RADIO
MEDIA
A/C
3 Remove (4) 7mm screws from the radio and climate
control bezel.
MENU
TEMP
BACK
RADIO
MEDIA
A/C
4 Disconnect and remove the radio tuner by lifting
the center tab. Use a pair of pliers to remove the
FM and SXM antenna connectors. Remove the CD
player by extracting (2) 7mm factory screws.
5 Remove the climate control module by carefully
unclipping it from factory panel. (This will later be
installed into the restyle bezel).
6 Extract (2) T15 Torx screws and unsnap the knee
cover on the driver side.
To Next Page
