Setting and adjustment of currents ----------------------------------------------------------------------------------------------
SETTING OF THE CURRENTS FOR CUT / COAGULATING CUT
Select the area
10 - CUT of currents by pushing the keys 4A or 5A
(The display of the deactivated area blinks).
Push the key
4A and select the first current you like. For example, PURE = pure cut (the related led switches on).
Adjust by keys
5A
the power (The display shows it). You can change the power always, even during the power delivery.
If you like, push again the key
4A to select a second current and adjust its power in the same way.
In the same way you can set all currents
By pushing the key 4A, all currents can be selected progressively (PURE > P
PULSED
> BLEND > B
PULSED
1 > B
PULSED
2 > PURE >>)
PURE – Pure cut P
PULSED
– Pulsed pure cut
BLEND – Coagulating cut B
PULSED
1 – Pulsed coagulating cut B
PULSED
2 – Slowly pulsed coagulating cut
At the end push the key 4A and select the first current you prefer to start the operation.
As above detailed, you can always change currents and/or powers during use.
SETTING OF THE CURRENTS FOR MONOPOLAR OR BIPOLAR COAGULATION.
Select the area 9
- COAG of currents by pushing the keys 4B or 5B
(The display of the deactivated area blinks).
Push the key
4B and select the first current you like. For example, MICRO – micro coagulation (the related led switches on).
Adjust by keys
5B the power (The display shows it). You can change the power always, even during the power delivery.
If you like, push again the key
4B to select a second current and adjust its power in the same way.
In the same way you can set all currents
By pushing the key 4B, all currents can be selected progressively (MICRO > M
PULSED
> FULG > F
PULSED
> BIPOLAR > MICRO >>)
MICRO – Delicate coagulation M
PULSED
– Pulsed delicate coagulation
FULG - Macro coagulation “fulguration” F
PULSED
– Pulsed macro coagulation “fulguration”
BIPOLAR – Bipolar coagulation
At the end push the key 4BA and select the first current you prefer to start the operation.
As above detailed, you can always change currents and/or powers during use.
Temporization of the Micro coagulation (from 0.1 to 1 sec) --------------------------------------------------------
Push the key 4B and select the M
PULSED
current.
Push again the key
4B for 3/4 seconds
The display changes and shows times: from one tenth of second (1.) to one second (10).
Adjust the time by keys
5B and push again the key 4B
(The display shows again the power level).
The device memorizes the set time that can be always changed in the same way to set the best value in order to obtain the
proper result.
Activation of all currents by the foot-switch ------------------------------------------------------------------------
To activate a cut current select the area
10-CUT by pushing keys 4A or 5A (The display of the deactivated area blinks).
If you want to use a current different from the already memorized one, select it by the key
4A
Push the foot-switch (the unit signals the activation by the yellow light ON and a grave sound).
To activate a coagulation current select the area
10-COAG by pushing keys 4B or 5B (The display of the deactivated area
blinks).
If you want to use a current different from the already memorized one, select it by the key
4B
Push the foot-switch (the unit signals the activation by the blue light ON and an acute sound).
To use pulsed currents (P
PULSED
, B
PULSED
1, B
PULSED
2 and F
PULSED
) push the pedal continuously.
The delivery is automatically pulsed.
To use the temporized monopolar coagulation M
PULSED
push the pedal.
Each time you push the pedal the delivery is very short (from 0,1 to 1 second) automatically.
By pushing both pedals together the self-test system blocks the device (See: AUTOMATIC SELF-TEST SYSTEM).
Activation of monopolar currents by the hand-switch pencil (Only in the model SU140-MPC)-
Activate the power delivery directly by pushing the buttons of the pencil (yellow = cut) (blue = coagulation).
The device operates as above detailed for the single foot-switch.
Memorization of settings and abnormal power delivery ------------------------------------------------------------
The device memorizes all settings automatically and it resets at the switching ON those used at the switching OFF.
In case of abnormal power deliveries see paragraphs AUTOMATIC SELF-TEST SYSTEM and IMPORTANT WARNINGS (Specially
the point Use of currents and powers)
