Description and operation
General description of the circuit--breaker
L12--0012EN/01
3/6
11--2012
© ALSTOM 2010. All rights reserved. Information contained in this doc ument is indic ative only. No representation or warranty is given or should be relied on
that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances. It is provided without
liability and is subject to change without notice. Reproduction, use or disclosure to third parties, without express written authority, is strictly prohibited.
GRID
Bearing structure
Description
The support--frame (10) -- made up with four supports fastened to the housing
(3) -- supports all the circuit--breaker components.
The support--frame may be supplied by either ALSTOM Grid or the custom-
ers.
Diagram
10
3
