Description and operation
General description of the circuit--breaker
L12--0012EN/01
4/6
11--2012
© ALSTOM 2010. All rights reserved. Information contained in this doc ument is indic ative only. No representation or warranty is given or should be relied on
that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances. It is provided without
liability and is subject to change without notice. Reproduction, use or disclosure to third parties, without express written authority, is strictly prohibited.
GRID
Operating d evice
Description
The operating device (11) is a spring operating mechanism of the FK3--5 type.
The door of the operating device (11) is equipped with two windows. These
windows permit to display the optical signalization of the circuit--breaker state
and closing spring state.
Diagram
3
11
Fastening
The operating device is fastened on the housing (3).
