Alstom MX3IPG2A - Appendix A - Network Data Exchange

pag. 36
MDE/C133 2561 001 MX3IPG2A
APPENDIX A - Network data exchange
DESCRIPTION DIRECTION TIMING
Identification
commercial name relay--> centre AR
plant identifier relay--> centre AR
direct voltage range relay--> centre AR
Setting data (main and spare)
settings in use relay--> centre--> relay AR
date of last change relay--> centre--> relay AR
time of last change relay--> centre--> relay AR
language in use relay--> centre--> relay AR
rated frequency relay--> centre--> relay AR
direct rated voltage relay--> centre--> relay AR
LCD setting relay--> centre--> relay AR
min. pulse width of end relay relay--> centre--> relay AR
timer t_X1 delay relay--> centre--> relay AR
timer t_X2 delay relay--> centre--> relay AR
timer t_X3 delay relay--> centre--> relay AR
first underresistance threshold included/excluded relay--> centre--> relay AR
first underresistance threshold value relay--> centre--> relay AR
first underresistance threshold starting delay relay--> centre--> relay AR
trip delay per first underresistance threshold relay--> centre--> relay AR
second underresistance threshold included/excluded relay--> centre--> relay AR
second underresistance threshold value relay--> centre--> relay AR
second underresistance threshold starting delay relay--> centre--> relay AR
trip delay for second underresistance threshold relay--> centre--> relay AR
overcurrent threshold included/excluded relay--> centre--> relay AR
overcurrent threshold value relay--> centre--> relay AR
overcurrent threshold starting delay relay--> centre--> relay AR
overcurrent threshold trip delay relay--> centre--> relay AR
first dir. undervoltage threshold included/excluded relay--> centre--> relay AR
first dir. undervoltage threshold value relay--> centre--> relay AR
first dir. undervoltage threshold starting delay relay--> centre--> relay AR
trip delay for first dir. undervoltage threshold relay--> centre--> relay AR
second dir. undervoltage threshold included/excluded relay--> centre--> relay AR
second dir. undervoltage threshold value relay--> centre--> relay AR
second dir. undervoltage threshold starting delay relay--> centre--> relay AR
trip delay for second dir. undervoltage threshold relay--> centre--> relay AR
first dir. overvoltage threshold included/excluded relay--> centre--> relay AR
first dir. overvoltage threshold value relay--> centre--> relay AR
first dir. overvoltage threshold starting delay relay--> centre--> relay AR
trip delay for dir. overvoltage threshold relay--> centre--> relay AR
second dir. overvoltage threshold included/excluded relay--> centre--> relay AR
second dir. overvoltage threshold value relay--> centre--> relay AR
second dir. overvoltage threshold starting delay relay--> centre--> relay AR
trip delay for second dir. overvoltage threshold relay--> centre--> relay AR
Present measurementsi
resistance relay--> centre T e AR
direct voltage relay--> centre T e AR
alternating voltage relay--> centre T e AR
alternating current relay--> centre T e AR
Maximum measurements
overcurrent relay--> centre AR
