wheel (E) (see page 7 fig. 5)
2. Insert the set point correction limiter (F) to the desired place in the setting wheel (E).
6.2 Temperature limitation
The temperature range for the target temperature to be set as a maximum and a
minimum can be limited via the set value elements on the inside of the setting
wheel (E) (see page 7 fig. 6).
1. Remove setting wheel (E). Read the scale for the limitation on the inside of the
setting wheel (E).
2. Insert the target value elements (G) into the setting wheel (E) indicating the de-
sired range.
6.2.1 Connection test
During this verification the room control unit Analog sends a switching command to
the base station. Depending on the switching status the assigned heating zone has,
it will be switched on or off after receiving the command.
1. Remove setting wheel (E).
2. Press the Set button in order to perform a radio test.
