English
18 4175654-Ed.01 (2013/01)
2 Technical data
2.1 Data
* Reference value for the most efficient circulation pumps: EEI 0.20
2.2 Scope of delivery
•Pump
• Thermal insulation shell (depends on version)
• Sealing rings
• Plug included
• Installation and operating instructions
CPA
Connection voltage 1 ~ 230 V ±10%, 50/60 Hz
Temperature class TF 95
Protection class IP See rating plate
Energy Efficiency Index EEI * See rating plate
Nominal connection diameter
(threaded connection)
DN 25 (Rp 1)
Water temperatures at max.
ambient temperature of +40°C
-10°C to +95°C
Max. ambient temperature -10°C to +40°C
Max. operating pressure 6 bar (600 kPa)
Minimum inlet pressure
at +95°C
0.3 bar (30 kPa)
