TS312
Output Power
2000 watts
(peak, 1300 LF + 700 HF), 1000 watts (continuous, 650 LF + 350 HF)
Drivers Low-Frequency: 12.0” (305 mm) driver, 3.0” (76 mm) high-temperature
voice coil
High-Frequency: 1.4” (35 mm) neodymium driver with precision waveguide
Crossover Frequency
2.0 kHz
Maximum SPL
131 dB
(peak), 128 dB (continuous) (dB-SPL @ 1 m)
Frequency Response
53 Hz – 20 kHz
(+3 dB)
Frequency Range
46 Hz – 22 kHz
(-10 dB)
Horn Coverage
90° horizontal x 60° vertical
(nominal)
Equalization
Contour switch with low- and high-frequency +3 dB boost
Connectors
(2) XLR+1/4” (6.35 mm) TRS combo inputs
(1) XLR output
(Link)
(1) IEC power cable input
Controls
Power switch, (2) volume control knobs
(1 per input), contour switch,
ground-lift switch
Indicators
(2) power LEDs
(1 front panel, 1 rear panel), clip limiter LED
Power Connection: IEC
Voltage: 100 V~, 110–120 V~, 220–240 V~, 50/60 Hz, switchable
Fuse: 100–120V T10AL AC250V, or 220–240V T5AL AC250V
Consumption: 800 W
Protection
Electronic clip, thermal and transducer overdrive protection
Enclosure
Trapezoidal, injection-molded, polypropylene with perforated steel grille
Mounting/Installation
Standard 36 mm pole socket, wall or ceiling mount with TSB125 bracket,
suspended with integral M10 points, wedge monitor
Dimensions
(height x width x depth)
23.8” x 13.9” x 13.8”
605 x 354 x 350 mm
Weight
35.9 lb.
16.3 kg
