#8405 — QUICKCHILLER INSTALLATION, OPERATION, AND MAINTENANCE
Pg. 32.
®
SERVICE VIEW
POWER SUPPLY BOARD
BA-33554
RM3
R
ELAY
BA-34021
RM1
R
ELAY
BA-34009
RM2
R
ELAY
BA-34010
C
IRCUIT BREAKER
SW-34152
FUSE BLOCK
FU-3772
CONTACTOR
PCCC58
FUSE, 15 AMP
FU-3775
MODEL: QC-3 CONTROL
