#8405 — QUICKCHILLER INSTALLATION, OPERATION, AND MAINTENANCE
Pg. 33.
MODEL: QC-3 COIL
FAN
TERMINATOR
CR-33387
EVAPORATOR COIL
SIDE RACK,
LEFT-HAND
SIDE RACK,
RIGHT-HAND
COIL SENSOR
14285
TXV VALVE
VA-34216
D
EFROST
H
EATER
CB-33389
EVAPORATOR
COIL FAN
MOTOR
MO-33385
A
IR SENSOR
SN-33541
P
RODUCT PROBE
PR-3850
®
SERVICE VIEW
