Alto ELVIS 15M User Manual

1 2 3 4
A B C D
4321
D C B A
+ _
IN
L1
1.55mH (BIG)
P1 +
C1
6.8uF /250V
P2
_
C2
3.3uF/250V
R2
1R5/20W
L2 0 35mH
C4
JUMP
R4 39R/20W
R3
10R/20W
DS1
I2V 2.1A
DS2
I2V 2.1A
PTC2
0.5A/60V
P3 +
P4
_
WOOFER
DRIVER
(BLACK)
_
(BROWN)
+
(BLACK)+ (BLUE)
_
LOW
HI
Hi O/P
R1
3R3/20W
PTC1 JUMP

Alto ELVIS 15M Specifications

General

Brand	Alto
Model	ELVIS 15M
Category	Speakers
Language	English
