ELVIS10A ELVIS12A ELVIS15A ELVIS12MA
150Watt IHF 250Watt IHF 350Watt IHF 250Watt IHF
120Watt RMS 180Watt RMS 250Watt RMS 180Watt RMS
117.5 dB ( IHF Power ) 121 dB ( IHF Power ) 123 dB ( IHF Power ) 121 dB ( IHF Power )
Line 0dB/0.775V/Mic-10 at -45dB
30kOhms Balanced - 15kOhms Unbalanced
Mic on XLR/Line Input on Combo/Line-Mix Output on XLR
30Hz - 24dB/oct. 30Hz - 24dB/oct. 30Hz - 24dB/oct. 30Hz - 24dB/oct.
Soft - Start DC voltage protect - compressor
Mic Gain - EQ-High-Mid-Low-Volume-Ground Switch
230Volt/115Volt 50 / 60Hz
Output Power IHF
Output Power RMS
Max SPL at 1mt
Input Sensitivity
Input Impedance
Connectors
Subsonic Filter
Protections
External Control
Power Supply
Net Weight lbs/kg
Gross Weight lbs/kg
Shipping Volume
40.12lbs/18.2kg
46.83lbs/21.24kg
4.58CFT
50.95lbs/23.11kg
58.89lbs/26.71kg
6.03CFT
62.83lbs/28.5kg
71.52lbs/32.44kg
7.35CFT
49.54lbs/22.47kg
56.92lbs/25.82kg
6.10CFT
ELVIS12SA ELVIS15SA
250Watt IHF 350Watt IHF
180Watt RMS 250Watt RMS
121 dB ( IHF Power ) 123 dB ( IHF Power )
230Volt/115Volt 50/60Hz
Volume - Stereo/Mono & Ground Swicth
Electronic Crossover 125Hz at 24dB/oct.
Line 0dB/0.775V
30kohms-input/600ohms-output
L/Mono-R IN on XLR/L-R OUT on XLR
Output Power IHF
Output Power RMS
Max SPL at 1mt
Input Sensitivity
Input Impedance
Connectors
Subsonic Filter
Protections
External Control
Power Supply
Net Weight lbs/kg
Shipping Volume
Gross Weight lbs/kg
60.36lbs/27.38kg
67.19lbs/30.48kg
6.15CFT
76.68lbs/34.78kg
85.72lbs/38.88kg
8.67CFT
Soft start-DC voltage protect -compressor
2. Technical Specification & Thansistor Packages
Transistor Packages
TO92
2SC1815, 2SA1015:
2N5401, 2N5551:
1=Emitter
2=Collector
3=Base
1=Emitter
2=Base
3=Collector
TO126
MJE340, MJE350,
MJE802:
1=Emitter
2=Collector
3=Base
4=Collector
TO220
MJE15030, MJE15031:
1=Base
2=Collector
3=Emitter
4=Collector
TO218
TIP35C, TIP36C:
1=Base
2=Collector
3=Emitter
4=Collector
TO264
2SC5200, 2SA1943:
1=Base
2=Collector
3=Emitter
4=Collector
1
2
3
3
2
1
1
2
3
4
4
1
2
3
4
3
2
1
4
