No. Part No. Descriptions Specification Remark
242 SG00014 SMD integrated circuit NJM13700M
243 SF00053 transistor MMBT3906(SOT-23)/(PHI) Q100,Q172,Q175,Q200
244 SF00056 transistor MMBT3904(SOT-23)/(PHI) Q101,Q102,Q171,Q173
245 AE00221 tin soldering paste SJ-617
246 NC00129 insulation 0.3t*45*24mm
247 RA00583 precise resistor 1/4W
470KΩ M type
248 AC00002 solder wire 63/37%
249 HK01379 PC board P-PSA-31300-B-DIP
250 RA00142 fixed resistor 1/2W
15KΩ M type
R265
251 RA00007
metal-oxide-film resistor 1W
22Ω P type
R236,R237
252 RA00050
metal-oxide-film resistor 2W
1.5Ω P type
R281,R282
253 RA00051
metal-oxide-film resistor 2W
5.6Ω P type
R260
254 RA00055
metal-oxide-film resistor 3W
12Ω RSS P type
R254,R255,R261,R262
255 RA00065
metal-oxide-film resistor 3W
2.2KΩ RSS P type
R257,R258,R298
256 RA00068
metal-oxide-film resistor 3W
8.2KΩ RSS P type
R218,R219,R233,R235
257 RA00091
cement resistor 5W
0.2Ω(P)
R203,R242,R248,R249,R252,
R253,R256,R259
258 RA00067
metal-oxide-film resistor 3W
5.1KΩ RSS P type
R280,R288
259 CB00017 electrolytic capacitor
4.7uF/250V φ10*12mm
C7
260 CB00041 electrolytic capacitor
47uF/50V φ6*11mm
C8
261 CB00157 electrolytic capacitor
12000uF/80V φ35*56mm
C220,C221,C222,C223
262 CC00004 Mylar capacitor 0.0015uF/100V 10% C214
263 CC00009 Mylar capacitor 0.0033uF/100V 10% C272,C279
264 CC00027 Mylar capacitor 0.022uF/100V 5% C216,C219
265 CF00013 metal-film capacitor MEF 0.068uF/250V C224,C226
266 CF00033 metal-film capacitor MEF 0.1uF/250V C274,C275
267 SA00098 rectifier diode 1A/400V IN4004 D1,D11,D13,D217,D218
268 SA00002 high speed diode 1A/600V 1N4937 D208,D209
269 SA00107 zener diode 1W 15V 1N4744 D15,D8
270 SA00117 zener diode 1/2W 5.6V 6B1 D207,D210,D270
271 SB00034 transistor 2SC1815GR Q5
272 SB00042 transistor MJE15032 Q205
273 SB00044 transistor MJE15033 Q206
274 SB00021 power transistor 2SC5200 Q204,Q208,Q210,Q212
275 SB00023 power transistor 2SA1943-O Q203,Q207,Q209,Q211
276 RC00161 resistor
3.3KΩ φ6 3P 3318F-1-332
R239,R240
277 RC00163
carbon-film semi-fixed resistor
100Ω φ6 3P horizontal 3318P-1-
101
R231
278 RH00004 thermistor
90Ω (NSA05A090L-500)
R234
279 RH00005 thermistor
100Ω (PTH9M04BH471TS2F333)
R7
280 HC00076 row-wire header 2P 2.5mm 180° CN202
281 HC00077 row-wire header 3P 2.5mm 180° CN203
282 HC00262 row-wire header 13P 2.0mm 180° CN201
283 CN00028 inductance 10*21.8mm
284 HC00324 terminal 6.5m/m (PC250)
