4
Quick Start
Items not listed under Introduction > Box Contents are sold separately.
Example A: 1 subwoofer & 2 loudspeakers
Using XLR cables, connect the left and right outputs of your mixer to the inputs of your
subwoofer, and then connect the outputs of the subwoofer to the input of each loudspeaker.
Example B: 2 subwoofers & 2 loudspeakers
Using XLR cables, connect the left and right outputs of your mixer to Input 1 of each
subwoofer, and then connect Output 1 of each subwoofer to the input of each loudspeaker.
Loudspeaker
Mixer
Power Power
Subwoofer Loudspeaker
Loudspeaker Subwoofer Loudspeaker Subwoofer
Mixer
Power Power Power
