Altrad Belle DC 300E+ - Main Components Locations

7
Machine Description
GB
MAIN COMPONENT LOCATIONS
A. Blade Guard.
B. Front Handle.
C. Trigger Lock-Out Button.
D. Trigger.
E. Rear Handle.
F. Cutting Blade.
G. 13mm Spanner.
H. Water Feed Coupling.
J. Water Flow Valve.
K. Guard Adjustment Lever
K
Q
E
L
S
H
D
P
G
N
A
B
C
M
R
J
F
T
U
L. Spindle Lock Button.
M. Blade Securing Screw.
N. Blade Clamping Plate.
P. On/O󰀨Button
Q. Battery Release Latch.
R. LEDLightOn/O󰀨Button.
S. LED Light.
T. Warning Light.
U. Battery
V. Magnetic Filter Cover
V
